COM14913
Scroll Compressor, Fixed (Baseline), 57,500 BTU/h, 4.75 tons, R-410A, 200-230V, Three Phase, 50/60 Hz, 7/8 in. Suction, 1/2 in. Discharge
Login /Create Account to view price and availability.
Export Product Details
Brand
Alliance
Connection Type
Brazed, Stub Tube
Current (Amps)
15.2
Discharge Connection Size (OD)
1/2
Frequency (Hz)
50/60
Horsepower (HP)
5
Modulation Type
Fixed (Baseline)
Mounting Dimensions (L x W)
7.50 x 7.50
Oil Type
POE (Polyolester Oil)
Overall Height (In)
16.47
Overall Length (In)
9.69
Overall Width (In)
9.69
Phase
3
Protection Type / Housing
Hermetic
Refrigeration Capacity (Ton)
4.75
Shipping Dimension UOM
IN
Shipping Height
20.0
Shipping Length/Depth
14.5
Shipping Weight
80.0
Shipping Weight UOM
LB
Shipping Width
13.0
Speed (RPM)
3500
Standards
UL
Suction Line Size (OD)
7/8
Voltage (VAC)
200-230V
